composite machine beds

AC generator coupled to a DC machine coupled to another DC machine coupled to an AC motor, enabling students to perform various experiments at the same setup,test-bed is equipped with an autotransformer as well,All experiments related to DC machines and AC machines both motor and generator can be done by using this setup (no-load,full load and blocked rotor test etc.,).machine terminals,controlling MCBs,AC/DC indicators,AC/DC output terminals and digital meters are arranged in panel boards.
